Shure
Out of Stock
Domestic Multi-Carrier Shipping · 2-Year Warranty · Expert Support
Feature
Model
MV-TWO-KIT-Z7
UPC
042406772792
| Specification | Value | Info |
|---|---|---|
| Frequency Response | 50-20kHZ +/-1dB | Audio |
| Dynamic Range (A-Weighted) | 100dB | Audio |
| Equivalent Noise (A-Weighted, Camera Out = Line Level) | 31 dBSPL | Audio |
| Equivalent Input Noise (A-Weighted, Direct to phone) | 26 dBSPL | Audio |
| Max Sound Pressure Level (SPL) | 130dBSPL | Audio |
| Sensitivity when used with MV-LAV (Mic Gain = 0dB) | -45dBV @94dBSPL (1 Pascal RMS) | Audio |
| Bit Depth | 24 Bit | Audio |
| Sampling Rate | 48ksps or 44.1ksps (Host dependent) | Audio |
| Gain Adjustment Range | 0 - 60 dB | Audio |
| Minimum Load Impedance – HP | 16 ohms | Audio |
| Maximum Headphone Output Level |
| 26.4mW @1% THD |
| Audio |
| Minimum Load Impedance - Camera Out | 2k ohms | Audio |
| Maximum Camera Output Level (Mic Setting) | -26dBV | Audio |
| Maximum Camera Output Level (Line Setting) | -8.3dBV | Audio |
| Latency to 3.5mm (without NR) | 15.33 ms (within 1 frame @60fps) | Audio |
| Latency to 3.5mm (with NR) | 17.33 ms | Audio |
| Latency to USB | Device Dependent Host Device Dependent | Audio |
| Range | Up to 100ft (30m) line of sight | Audio |
| Overall Dimensions (w/o windscreen) | 1.81" x 0.87" x 0.59" | Physical Specifications (Microphones) |
| Weight (w/o windscreen) | 8.2 g [0.29 oz] | Physical Specifications (Microphones) |
| Housing | Black PC/ABS Thermoplastic | Physical Specifications (Microphones) |
| Antenna | Sheet metal with copper-nickel-zync alloy | Physical Specifications (Microphones) |
| Overall Dimensions (with cold shoe mount fully extended) | 2.55" x 2.64" x 0.75" | Physical Specifications (Receiver) |
| Weight (w/o windscreen) | 81 g [2.86 oz] | Physical Specifications (Receiver) |
| Housing | Black PC/ABS Thermoplastic | Physical Specifications (Receiver) |
| Antenna | Sheet metal (tin-plated steel) | Physical Specifications (Receiver) |
