NAD Electronics
SKU: NAD-ELECTRONICS-C
In Stock
Feature
PowerDrive™ Technology
Feature
High-Precision MM Phono Input
Feature
Six Versatile Inputs
Feature
Defeatable Tone Controls
Feature
Compact and Elegant Build
Exceptional Audio Performance
Equipped with NAD's renowned PowerDrive™ technology, the C 316BEE V2 provides a robust 40 watts per channel of continuous power, ensuring dynamic and distortion-free sound reproduction. Its high current design adeptly handles complex speaker loads, delivering impressive dynamic power exceeding 100 watts when needed.
Vinyl-Ready with Precision Phono Stage
Catering to vinyl enthusiasts, this amplifier includes a high-precision MM phono input. The sophisticated RIAA phono stage combines low noise with high overload margins to eliminate noise and distortion, ensuring accurate playback of your cherished records.
User-Friendly Design
The C 316BEE V2 focuses on essential features to enhance user experience. It offers six inputs, including five line-level inputs and a front-panel 3.5mm input for portable media players. A full-function remote control, defeatable tone controls, and a front-panel headphone jack provide added convenience.
Eco-Conscious Engineering
Demonstrating a commitment to environmental responsibility, the amplifier boasts improved power efficiency and consumes less than 0.5 watts in standby mode. Its construction utilizes lead-free solder and is free from hazardous materials, reflecting NAD's dedication to eco-friendly design.
Model
C 316BEE V2
UPC
5703120232584
| Specification | Value | Info |
|---|---|---|
| THD (20Hz - 20kHz) | <0.03% in 300 ohms at 2V out | Line In/Headphone Out |
| Signal-to-noise ratio | >100dB (A-weighted, 32 ohms, ref. 2V out, unity gain) | Line In/Headphone Out |
| Frequency response | ±0.3dB (20Hz - 20kHz) | Line In/Headphone Out |
| Output impedance | 68 ohms | Line In/Headphone Out |
| Continuous output power into 8 ohms and 4 ohms | 40W (ref. 20Hz - 20kHz at rated THD, both channels driven) | Line In/Speaker Out |
| THD (20Hz - 20kHz) | <0.03% (250mW to 40W, 8 ohms and 4 ohms) | Line In/Speaker Out |
| >95dB (A-weighted, 500mV input, ref. 1W out in 8 ohms) | Line In/Speaker Out | |
| >97dB (A-weighted, 500mV input, unity gain in 32 ohms) | Line In/Speaker Out | |
| >45W in 8 ohms | Clipping power (at 1kHz 0.1% THD) | |
| >60W in 4 ohms |
| Clipping power (at 1kHz 0.1% THD) |
| 8 ohms | 90W | IHF dynamic power |
| 4 ohms | 120W | IHF dynamic power |
| 2 ohms | 170W | IHF dynamic power |
| THD (20Hz - 20kHz) | <0.03% (1W to 40W, 8 ohms and 4 ohms) | Phono In/Speaker Out |
| Signal-to-noise ratio | >75dB with IHF MM cartridge (A-weighted, ref. 5mV input 1kHz and 1W output in 8 ohms) | Phono In/Speaker Out |
| Frequency response (RIAA deviation) | ±0.3dB (20Hz - 20kHz, Tone Defeat ON) | Phono In/Speaker Out |
| Maximum input level | 71mV (1kHZ THD 0.1%) | Phono In/Speaker Out |
| Input sensitivity (for 40W in 8 ohms) | 2.95mV | Phono In/Speaker Out |
| Dimensions (W x H x D) | 17 1/8" x 3 9/16" x 11 1/4" | Dimensions and Weight |
| Weight | 12.1 lbs. | Dimensions and Weight |
